Thermally Broken Out-Swing Single Shower/Sauna Door

Style: TB 6000

Hot-formed steel single doors from Portella are distinctive for their narrow sight lines and exceptional strength that make them perfect for today’s contemporary architecture. Influenced by European aesthetic design, their thin, solid steel frames and stiles create a distinctively narrow sight line that lends a timeless, minimalist feel. Select from a variety of finishes including pewter, bronze, black or a custom finish created just for your project.

Diagram of Portella Thermally Broken Out-Swing Single Shower/Sauna Door
thermally-broken-out-swing-single-shower-sauna-door

Thermally Broken Out-Swing Single Shower/Sauna Door

  • NFRC rated Thermally Broken
  • Carbon Steel (Stainless Steel, CorTen, and Bronze available)
  • Precision cold formed profiles with “stepped leg” design
  • High density cast in polyurethane thermal barrier
  • Double glazed (single and triple available)
  • Glass: Cardinal 366/Argon/Clear tempered (other glass options available)
  • Glazing Orientation: Exterior Wet Glazed
  • True divided lite construction with 1 ¼” muntin bars
  • Hinges: Adjustable steel post in barrel w ball bearing
  • Door Lock: Rocky Mountain trim with Accurate mortise lock. 1 ¾”backset.
  • Sill: Custom brass height varies per floor requirements
  • Available in standard and custom paint options: grey, pewter, gun metal, chestnut brown, dark bronze and black
  • Continuous steel mounting flanges with orientation options

Available Finishes

*Patina finishes available upon request.

  • Pewter
  • Gun Metal
  • Grey
  • Brown
  • Dark Bronze
  • Black

Available Hardware

*Others by approval.


  • Rocky Mountain

  • Hoppe
Warranty

Portella Custom Doors, LLC., warrants its steel doors, windows and glass, to be free from defect in material and workmanship (excluding finish) and will repair or replace any defective product or parts at Portella Custom Doors’ sole discretion. Portella also warrants factory-applied product finishes. Each of our product lines carry exceptional limited warranties as indicated:

Artisan Series products have a limited 20-year material warranty, a 10-year limited warranty on glass, and a 5-year warranty on finishes (Specialty Glass, Hardware or Finishes Manufacturer warranty applies).

Classic Series products carry a limited 10- year material warranty, a 10-year limited warranty on glass, a 5-year limited warranty on finish. (Specialty Glass, Hardware, or Finishes Manufacturer warranty applies).

Storefront Exterior Series products carry a limited 5-year material warranty, a 10-year limited warranty on glass, and a 5-year limited warranty on finish. (Specialty Glass, Hardware, or Finishes Manufacturer warranty applies).

Hardware see manufacturers warranty
