Thermally Broken Awning Window
Bring the outdoors inside—even during a light rain. Portella thermally broken awning windows are hinged at the top so that you can push out the sash and ventilate hot air while keeping drizzling weather outside. Perfect for a clerestory to keep light in and allow hot air to escape. Made of solid steel, our awning windows can be automated or manually operated by a crank and are similar to the construction of our hopper window.
Thermally Broken Awning Window
- NFRC rated Thermally Broken
- Carbon Steel (Stainless Steel, CorTen, and Bronze available)
- Precision cold formed profiles with “stepped leg” design
- High density cast in polyurethane thermal barrier
- Double glazed (single and triple available)
- Glass: Cardinal 366/Argon/Clear tempered (other glass options available)
- Glazing Orientation: Exterior Wet Glazed
- True divided lite construction with 1 ¼” muntin bars
- Hinges: Adjustable steel post in barrel w ball bearing
- Window Lock: Latch sash lock
- Window Operation: Stay bar or roto crank
- Available in standard and custom paint options: grey, pewter, gun metal, chestnut brown, dark bronze and black
- Continuous steel mounting flanges with orientation options
- Minimum size 12” width x 12” height
- Maximum size 72” width x 36” height
Available Finishes
*Patina finishes available upon request.
-
Pewter
-
Gun Metal
-
Grey
-
Brown
-
Dark Bronze
-
Black
Available Hardware
*Others by approval.
-
Roto Operator
Portella Custom Doors, LLC., warrants its steel doors, windows and glass, to be free from defect in material and workmanship (excluding finish) and will repair or replace any defective product or parts at Portella Custom Doors’ sole discretion. Portella also warrants factory-applied product finishes. Each of our product lines carry exceptional limited warranties as indicated:
Artisan Series products have a limited 20-year material warranty, a 10-year limited warranty on glass, and a 5-year warranty on finishes (Specialty Glass, Hardware or Finishes Manufacturer warranty applies).
Classic Series products carry a limited 10- year material warranty, a 10-year limited warranty on glass, a 5-year limited warranty on finish. (Specialty Glass, Hardware, or Finishes Manufacturer warranty applies).
Storefront Exterior Series products carry a limited 5-year material warranty, a 10-year limited warranty on glass, and a 5-year limited warranty on finish. (Specialty Glass, Hardware, or Finishes Manufacturer warranty applies).
Hardware see manufacturers warranty
