Storefront Interior Out-Swing Double Casement Window

Style: SFI 2200

Portella pairs precision engineering with elegant design to create a French casement steel window that brings your architectural vision to life. Sealed all the way around, our windows don’t make you choose between performance and energy efficiency. Hinged on the outside with no center mullion, the independent sashes give you a clear view as they push open like a French door and stay open with stay bars and latches, bringing the outside in

Diagram of Portella Storefront Interior Out-Swing Double Casement Window

Storefront Interior Out-Swing Double Casement Window

  • Carbon Steel
  • Single glazed
  • Glass: Tempered 1/4” Clear or Satin Etch
  • Glazing Stop: L shape metal stop
  • True divided lite construction with 1” muntin bars
  • Double casement designed with fixed center astragal
  • Hinges: Adjustable steel post in barrel w ball bearing
  • Window Lock: Latch sash lock
  • Window Operation: Stay bar
  • Available in standard and custom paint options: grey, pewter, gun metal, chestnut brown, dark bronze and black
  • Continuous steel mounting flanges with orientation options
  • Minimum size 24” width 12” height
  • Maximum size 72” w x 96” height

Available Finishes

*Patina finishes available upon request.

  • Grey
  • Dark Bronze
  • Black
  • Gun Metal
  • Pewter
  • Chestnut Brown

Available Hardware

*Others by approval.


  • Window Latch

  • Stay Bar
Warranty

Portella Custom Doors, LLC., warrants its steel doors, windows and glass, to be free from defect in material and workmanship (excluding finish) and will repair or replace any defective product or parts at Portella Custom Doors’ sole discretion. Portella also warrants factory-applied product finishes. Each of our product lines carry exceptional limited warranties as indicated:

Artisan Series products carry a limited 10-year product warranty, a 10-year limited warranty on glass and a 5-year warranty on finishes.Classic Series products carry a limited 10- year product warranty, a 10-year limited warranty on glass, a 5-year limited warranty on finish. Storefront Exterior Series products carry a limited 5-year product warranty, a 10-year limited warranty on glass, and a 5-year limited warranty on finish.Storefront Interior Series products carry a limited 5-year product warranty, a 10-year limited warranty on glass, and a 5-year warranty on finish.Hardware see manufacturers warranty
