Storefront Interior Double Out-Swing Casement with Fixed Window

Style: SFI 3000
Storefront Interior Out-Swing Casement Window

One of the most popular window styles in modern architecture, casement windows from Portella are perfectly designed for today’s tastes. With narrow mullions, they are hinged like doors on one side, so they open with a push and stay open with beautiful stay bars and latches to bring fresh air inside. Portella casement windows are sealed all the way around, keeping air from leaking and reducing noise. And they’re versatile, so they can be side-hung, top-hung or bottom-hung—or hung in combination, so that they can open from the left, the right or in the middle and control the direction of the incoming breeze

Diagram of Portella Storefront Interior Double Out-Swing Casement with Fixed Window
storefront-exterior-casement-to-fixed-window

Storefront Interior Double Out-Swing Casement with Fixed Window

  • Carbon Steel
  • Single glazed
  • Glass: Tempered 1/4” Clear or Satin Etch
  • Glazing Stop: L shape metal stop
  • True divided lite construction with 1” muntin bars
  • Hinges: Adjustable steel post in barrel w ball bearing
  • Window Lock: Latch sash lock
  • Window Operation: Stay bar
  • Available in standard and custom paint options: grey, pewter, gun metal, chestnut brown, dark bronze and black
  • Continuous steel mounting flanges with orientation options
  • Minimum size 12” width 12” height on casement + fixed window
  • Maximum size 12” w x 96” height

Available Finishes

*Patina finishes available upon request.

  • Grey
  • Dark Bronze
  • Black
  • Chestnut Brown
  • Gun Metal
  • Pewter

Available Hardware

*Others by approval.


  • Window Latch

  • Stay Bar
Warranty

Portella Custom Doors, LLC., warrants its steel doors, windows and glass, to be free from defect in material and workmanship (excluding finish) and will repair or replace any defective product or parts at Portella Custom Doors’ sole discretion. Portella also warrants factory-applied product finishes. Each of our product lines carry exceptional limited warranties as indicated:

Artisan Series products have a limited 20-year material warranty, a 10-year limited warranty on glass, and a 5-year warranty on finishes (Specialty Glass, Hardware or Finishes Manufacturer warranty applies).

Classic Series products carry a limited 10- year material warranty, a 10-year limited warranty on glass, a 5-year limited warranty on finish. (Specialty Glass, Hardware, or Finishes Manufacturer warranty applies).

Storefront Exterior Series products carry a limited 5-year material warranty, a 10-year limited warranty on glass, and a 5-year limited warranty on finish. (Specialty Glass, Hardware, or Finishes Manufacturer warranty applies).

Hardware see manufacturers warranty
